EISEDICHT Tyvek® Self-Adhesive Airtight Pipe Sealing Grommet

The EISEDICHT Tyvek® airtight pipe sealing grommet is a professional self-adhesive sealing solution designed for the permanent airtight and windtight sealing of pipe, cable and service penetrations through building envelope membranes. It helps prevent uncontrolled air leakage and moisture-related damage to building structures, making it suitable for energy-efficient construction and professional building installations.

The one-piece airtight sealing grommet features a self-adhesive Tyvek® sealing collar that is highly tear-resistant, water-repellent and resistant to ageing. The collar is coated with a strong polyacrylate adhesive, providing a durable connection to the building's airtight or windtight layer.

The integrated EPDM rubber sealing sleeve provides a permanently flexible seal around pipes and service lines. Manufactured from ageing-resistant EPDM rubber, the sleeve incorporates kink protection and integrated strain relief, helping accommodate minor structural movements and mechanical stress around the penetration.

The EISEDICHT Tyvek® GD series includes several variants for different pipe diameters. Depending on the selected model, the sealing sleeve height is 30 mm or 40 mm, while the self-adhesive collar measures 150 × 150 mm or 230 × 230 mm.

The grommets are suitable for interior and exterior applications, providing airtight sealing of penetrations through vapour barriers, vapour control membranes and other suitable airtight or windtight building envelope layers.

The products are designed in accordance with DIN 4108-7 and DIN 18015-5, supporting the airtightness requirements referenced in GEG 2020.

The listed GD variants are GTÜ tested and carry the Passivhaus seal.

Key Features

• Self-adhesive airtight sealing grommet for pipe and service penetrations.

• High-strength, tear-resistant Tyvek® sealing collar.

• Water-repellent and ageing-resistant construction.

• Strong polyacrylate adhesive for durable bonding.

• Permanently flexible EPDM sealing sleeve with integrated kink protection.

• Sleeve height of 30 mm or 40 mm, depending on the model.

• Integrated strain relief.

• Flexible seal accommodates minor structural movement.

• Available in different diameters for various pipe sizes.

• Allows subsequent adjustment or pulling of service lines.

• Simple, tool-free installation.

• Temperature resistance from -30 °C to +100 °C.

• Minimum installation temperature: +5 °C.

• UV-resistant.

• Halogen-free.

• Suitable for interior and exterior applications.

• Designed according to DIN 4108-7 and DIN 18015-5.

• GTÜ tested.

• Passivhaus seal.

Applications & Usage

The EISEDICHT Tyvek® pipe sealing grommet is designed for airtight sealing of pipe, cable and service penetrations through the building envelope, particularly where maintaining the continuity of airtight and windtight layers is essential.

Typical applications include electrical conduit penetrations, building service pipes, cables and other compatible installation lines passing through airtight membranes.

The grommets are suitable for residential and commercial construction, timber-frame buildings, energy-efficient houses and airtight building envelope systems.

Installation: Select the appropriate grommet according to the pipe or conduit diameter. Position the flexible EPDM sleeve around the penetration and bond the self-adhesive Tyvek® collar to the prepared airtight or windtight layer according to the manufacturer's installation instructions.

The permanently elastic sleeve helps maintain a durable seal while accommodating limited movement or subsequent adjustment of the installation line.

Available Sizes and Technical Specifications

General Technical Specifications

Advantages / Benefits

• Provides durable airtight sealing around pipe and service penetrations.

• Helps prevent uncontrolled air leakage and moisture-related building damage.

• Tear-resistant Tyvek® collar supports a reliable connection to airtight membranes.

• Strong self-adhesive polyacrylate coating simplifies installation.

• Permanently flexible EPDM sleeve accommodates limited structural movement.

• Integrated strain relief reduces mechanical stress around penetrations.

• Water-repellent and UV-resistant materials support indoor and outdoor use.

• Tool-free installation reduces additional installation steps.

• Available in multiple diameters for different pipe and conduit sizes.

• Suitable for airtight and energy-efficient building construction.

Application Industries / Use Cases

• Residential and commercial building construction.

• Electrical installation and conduit sealing.

• Plumbing and pipe installation.

• Building services installation.

• Airtight building envelope construction.

• Timber-frame and prefabricated construction.

• Energy-efficient and passive house construction.

• Building renovation and insulation.

• Construction membrane and vapour barrier installation.
